Φ365mm×149mm LED Outdoor Wall Lamp
Payment Terms: |
T/T,L/C |
Place of Origin: |
Zhejiang, China (Mainland) |
Product Detail
Model No.:
BD023-LED500×0.06W
Production Capacity:
3000pcs per week
Delivery Date:
30days
Base Material:
Aluminum
Diffuser:
Polycarbonate
Brand Name:
CHUANY
Power:
30W
Material:
Die-cast aluminum
Quantity:
500
CCT:
3000K / 6000K
IP Rank:
IP65
Means of Transport:
Ocean
Packing:
380mm×380mm×190mm
Voltage:
220v
Power Supply:
Others
Usage:
Garden
Input voltage:
AC220-240V
Dimensions:
Φ365mm×149mm
Source:
3528SMD
LED Initial Flux:
≥2700lm / ≥3000lm
CRI:
Ra≥80
* Power Efficiency: ≥80%
* LED Initial Flux:2700lm / 3000lm
Picture of Round Aluminium LED Outdoor Wall Light
Specification of Round Shape Aluminium LED Wall Lamp for Outdoor Using
Product Model | BD023-LED500×0.06W |
Input Voltage | AC 220V~240V |
Frequency Range | 50Hz/60Hz |
Power Factor | ≥0.9 |
Power Efficiency | ≥80% |
LED Power Consumption | 30W |
Power Consumption | 35.3W |
Dimensions | Φ365mm×149mm |
Material | Die-casted aluminum lamp body,PC cover |
Source | 0.06W 3528 |
LED Quantity | 500 |
LED Luminous Efficiency | 90lm/W / ≥100lm/W |
LED Initial Flux | 2700lm / 3000lm |
View Angel | 120° |
CCT | 3000K / 6000K |
Junction Temperature | ≤80℃(Ta=25℃) |
Lumen Attenuation | <5%@1,000Hrs |
Life Span | ≥30,000Hrs |
Working Temp | -20℃~55℃ |
Working Humidity | 10%~90% |
IP Rank | IP65 |
Size of Round Shape Aluminium Outdoor LED Wall Lamp with CE Listed
Features:long life span,energy saving,no radiation
