Hosing Round LED Downlights With Φ75mm Hole from China manufacturer - Zhejiang Chuanyang Lighting Technology Co.,LTD

Hosing Round LED Downlights With Φ75mm Hole

Price:	100.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: TH006-LED3x2W

Production Capacity: 3000 pieces/week

Delivery Date: 20 to 30 days

Hosing material: Aluminum die-cast

Hole Size: Φ75mm

LED Initial Flux: ≥480lm / ≥540lm

CRI: Ra≥80

IP Rank: IP44

Means of Transport: Ocean

Packing: 110mm×110mm×60mm

Input Voltage: AC 85V~265V

Dimensions: Φ90×45mm

Source: LEDS

CCT: 3000K / 6000K

LED Luminous Efficiency: ≥80lm/W / ≥90lm/W

* Life Span:≥30,000hrs
* Dimension:90mm×56mm
* Power Efficiency:≥70%

6W Aluminum Die-cast Φ90×45mm LED Ceiling Light With Anodized Surface

Size of the LED ceiling down light

Specifications of LED Ceiling light

Item	Description
Product Model	TH006-LED3×2W
Input Voltage	AC 85V~265V
Frequency Range	50Hz~60Hz
Power Efficiency	≥70%
LED Power Consumption	6W
Power Consumption	8w
Dimensions	Φ90×45mm
Hole Size	Φ75mm
Material	Aluminum, Anodized Surface
Source	1~3WLED
Quantity	3
LED Luminous Efficiency	≥80lm/W / ≥90lm/W
LED Initial Flux	≥480lm / ≥540lm
Lamp Efficiency	≥80%
View Angel	15°/30°/45°/60°
CCT	3000K/6000K
CRI	Ra≥70
Viewing Angle	15°/30°/45°/60°
IP Rank	IP44
Ambient temperature	-30~50℃
Ambient Humidity	≤70%
Junction Temperature	≤75℃(Ta=25℃)
Life Span	≥30,000hrs
Dimensions	110mm×110mm×60mm

Light distribution map:

Moden appearance and durable.

Features of LED ceiling lighting
1.long life span
2.Good quality and high brightness

Application:
Apply to home lighting,office,corridor ,bar and so on.

Picture of this 6W LED ceiling light
